UPort 1250/1250I

2-port RS-232/422/485 USB-to-serial converter with 2 KV isolation protection (optional)

UPort 1250/1250I

Instant Plug & Play

The UPort™ 1250/1250I USB-to-serial converters allow you to connect 2 RS-232/422/485 devices to your laptop or workstation through the USB (Universal Serial Bus) port. This plug & play USB solution is perfect for mobile, instrumentation, and point-of sale applications.

Simplified, Hassle-free Serial Port Expansion

USB plug & play makes serial port expansion easy, and does not require IRQ, DMA, or I/O address resources. Users no longer need to open the chassis or power down the system to add COM ports, saving on setup time and cost.

Top Serial Performance

Moxa’s 20-plus years of experience in serial board design is now built into a new top performance CPU called MOXA ART. This chip equips the UPort™ 1250/1250I converters with USB 2.0 (Hi-Speed 480 Mbps), a 128-byte FIFO, on-chip hardware and software flow control, and burst data mode, making Moxa’s UPort™ converters the top performing USB-to-serial converters in the world.

DATASHEET DOWNLOAD


Features and Benefits

  • Hi-Speed USB 2.0 for up to 480 Mbps USB transmission
  • 921.6 Kbps maximum baudrate for super fast data transmission
  • 128-byte FIFO and on-chip H/W, S/W flow control
  • 15N high retention type B connector
  • Drivers provided for Windows, WinCE, and Linux
  • LEDs for easy monitoring
  • 15 KV ESD protection for all serial ports
  • Locking power cord for the UPort 1250I
